产品详情
|
SIZE Nom. |
50mm (2") |
65mm (2-1/2") |
80mm (3") |
100mm (4") |
125mm (5") |
150mm (6") |
200mm (8") |
|
| D1 | 165 | 185 | 200 | 229 | 256 | 285 | 343 | |
| D2 | JIS | 120 | 140 | 150 | 175 | 210 | 240 | 290 |
| ANSI | 120.39 | 139.4 | 152.4 | 190.5 | 216 | 241.6 | 298.5 | |
| DIN | 125 | 145 | 160 | 180 | 210 | 240 | 295 | |
| D3 | 56.5 | 70 | 79 | 103 | 130 | 151 | 200 | |
| D4 | 105 | 120 | 123 | 135 | 164 | 169 | 200 | |
| L | 203 | 203 | 203 | 254 | 304 | 304 | 304 | |
| H1 | 246 | 266 | 276 | 318 | 390 | 405 | 466 | |
| H2 | 103 | 113 | 115 | 135 | 150 | 177 | 210 | |
| W1 | 42 | 46 | 46 | 56 | 66 | 71 | 87 | |
| W2 | 35 | 37 | 37 | 47 | 50 | 62 | 68 | |
| S3 | 93 | 94 | 94 | 100 | 110 | 100 | 120 | |
| n-ø e | JIS | 4-19 | 4-19 | 8-19 | 8-19 | 8-23 | 8-23 | 12-23 |
| ANSI | 4-19 | 4-19 | 4-19 | 8-19 | 8-22 | 8-23 | 8-22 | |
| DIN | 4-18 | 4-18 | 8-18 | 8-18 | 8-18 | 8-23 | 8-12 | |
